UNO Max: High-Power, Fast Charging Solution Home and Work
Introducing the UNO Max, Three-phase AC charging station for home or work. With 5m Mode 3 tethered cable type 2 and Type 2 Socket Outlet which provide efficient charging solution to meet your needs.
-
Auto Cut-off
-
IP65 Certified
-
IOT enabled
1.5-2 hr
Charging Time
22kW
Power
3P + N +PE
Input Type
WIFI / Ethernet / GSM
Connectivity
22 kW Smart Socket compatible with 2,3,4 wheelers
AC Input Voltage: 400V AC
AC Output Voltage: 410-440V AC
AC Output Current: 32 A/phase
Versatile and Powerful
The UNO Max 22kW Charger is a three-phase AC charging station designed for both home and work environments. It provides a robust and efficient charging solution, ensuring your electric vehicle is always ready to go.
Key Features:
- High Output Power: The UNO Max 22kW Charger offers a substantial charging power output of 22kW, catering to various charging needs.
- Advanced Connectivity: It supports multiple network connections via Ethernet, WiFi, or GSM, ensuring seamless integration and reliable performance.
- User-Friendly Interface: Equipped with a 4.3-inch LCD display, it provides clear information and easy navigation for users.
- Smart Security: Features high-security communication protocols, including S2W and OCPP 1.6 JSON, for secure data transmission.
- Robust Construction: The charger is built with galvanized steel and polycarbonate, offering IK10 mechanical impact resistance and IP55 waterproof rating, making it suitable for both indoor and outdoor use.
- Flexible Installation: Can be mounted on the ground or wall, providing flexibility in installation options to suit different environments.
- Comprehensive Protection: Includes overvoltage and undervoltage protection, overtemperature protection, and ground loss detection to ensure safety during charging.
Built-in Tethered Cable and Socket Outlet
The UNO Max 22kW Charger comes with a 5m Mode 3 tethered cable with a Type 2 outlet, facilitating easy and fast connections with your electric vehicle. It also includes a Type 2 socket outlet with a protective cap.
Efficient Load Management
The charger supports dynamic load management capabilities via a web platform, allowing for efficient energy distribution and preventing overloads.
User Identification and Customization
The charger utilizes RFID for user identification and can be managed using the Uno Charger phone app or any OCPP-compliant app. This feature allows for customization and remote monitoring, ensuring a user-friendly experience.
Environmentally Friendly
The UNO Max 22kW Charger is designed with a focus on sustainability, using materials that meet high-quality standards and are checked for their environmental impact.
